Tactile indicators & anti-slip
Request a QuoteTell us quantity, country and mounting type — a technical answer comes back the same day.
Digital application scenes illustrate how the product may be used; they are not records of completed customer projects.
Tactile indicators provide floor information that blind pedestrians can detect with the sole of the foot and a white cane. The function of dotted and ribbed patterns is selected for the application, orientation and project country accessibility scheme. Tactile surfaces are assessed with a layout plan for dropped kerbs, heads of stairs, platforms and building entrances. Profile dimensions, luminance contrast against the ground and slip resistance are confirmed separately for the selected product.
- Texture detected by foot and cane
- Pattern follows the country layout scheme
- Contrast and slip are assessed separately
Key features
- Dotted textureThe warning field is arranged for the application and the country accessibility scheme.
- Ribbed textureThe meaning of a ribbed pattern depends on orientation and country scheme; not every ribbed surface is a guidance surface.
- Detection by foot and caneThe relief carries the message detected through the ground; confirm profile dimensions for the selected product.
- Contrast with the groundAssess luminance contrast with the surrounding ground; a colour name alone is insufficient.
- Application selectionMatch the plate, existing ground, moisture conditions and fixing method together.
- Separate performance fieldsConfirm profile dimensions, contrast and slip resistance with their respective measurements or reports.
Technical summary
Downloadable design reference — nominal dimensions
| Plate dimensions | Both references: 600 × 300 × 3 mm plate with 5 mm relief; 8 mm overall height. |
|---|---|
| Attention pattern | TI-E6-TW600-P01-ATTENTION: 50 truncated-cone domes in a 10 × 5 layout. |
| Guiding pattern | TI-E6-TW600-P01-GUIDING: 8 capsule-shaped ribs in a 2 × 4 layout; each 240 × 30 × 5 mm. |
| Scope of dimensions | Dimensions refer to the identified downloadable design model; order dimensions and fixings are confirmed on the project drawing. |
Product and pattern
| Pattern function | Dotted or ribbed texture is selected with location and orientation under the country accessibility scheme. |
|---|---|
| Plate and profile dimensions | Plate dimensions, thickness, relief height and element spacing are confirmed against the selected model datasheet. |
| Material | Material grade and application method are confirmed together for the selected product. |
Ground and application
| Layout | Position, setback, warning field and route direction are defined in the accessibility design. |
|---|---|
| Fixing | Ground, moisture conditions, surface preparation, fixing method and reopening time are matched to product instructions. |
| Contrast and slip | Luminance difference against the ground and slip resistance are assessed with separate measurements or reports. |
Section and foundation
Installation
Method and tools needed
- Pattern and layout: Define the pattern, orientation and location in the country accessibility design; mark the installation line on site.
- Ground and fixings: Match plate material, ground and moisture conditions to product instructions. For bonded applications, obtain surface preparation and reopening time from the adhesive instructions.
- Final check: Verify profile, fixings, slip and contrast separately with the required measurements or reports; compare the layout with the accessibility design.
Maintenance and cleaning
- Relief and surrounding ground: Monitor wear and damage; include replacement planning in site maintenance.
- Fixings and edges: Assess the fixing if detachment or lifted edges are found; determine repairs from the actual material and fixing instructions.
- Cleaning and inspection: Follow the actual material manufacturer cleaning instructions; check relief, contrast and slip conditions after maintenance.
Where it is used
- Pedestrian crossing. The tactile warning field and position at the dropped kerb follow the country crossing scheme.
- Head of stairs. Tactile pattern, orientation and setback follow the applicable accessibility scheme for stairs.
- Platform and stop. The tactile warning field follows the platform and stop project layout scheme.
- Building entrance and terminal. The tactile guidance route connects entrances and service points under the accessibility design.
Ordering, documents and shipping
Ordering
- Minimum order
- There is no minimum order requirement. Mixed loads are accepted; you are not asked to fill a pallet or a container with a single item.
- Packing
- Export packing: shrink-wrapped pallets or cartons, with pallet size and gross weight stated on the packing list.
- Container
- The 40'HQ count depends on the height and variant chosen; the quotation states it with the pallet and container count.
- Lead time
- Set by the order quantity; the quotation states it in days and the shipment plan is fixed at order confirmation.
- Origin
- Stated in writing per item in the quotation.
- Delivery terms
- FOB · CFR · CIF · DAP
Shipping
- Pallet. State packaging and delivery scope for the selected tile/stud system in the quotation; confirm adhesive compatibility and colour/pattern combinations before ordering.
- 40'HQ. 40'HQ calculation
Downloads
- Technical document (PDF)
- Specification text (PDF)
- Technical drawings · sheet 1/2 · 1.7 MB
- Technical drawings · sheet 2/2 · 1.7 MB
- TI-E6-TW600-P01-ATTENTION · GLB · 777 KB
- TI-E6-TW600-P01-ATTENTION · STL · 2.1 MB
- TI-E6-TW600-P01-ATTENTION · FCStd · 12 KB
- TI-E6-TW600-P01-GUIDING · GLB · 74 KB
- TI-E6-TW600-P01-GUIDING · STL · 202 KB
- TI-E6-TW600-P01-GUIDING · FCStd · 12 KB
- All files: Downloads
The files are free to download and require no registration.
Standard reference
- ISO 23599official record
ISO 23599 gives product specifications and installation recommendations for tactile walking surface indicators for blind or vision-impaired people. It distinguishes an attention pattern and a guiding pattern.
The layout follows the applicable national accessibility rules and the site’s pedestrian routes; the standard does not replace national requirements.
Pattern and layout are matched to the project country accessibility requirements. Profile, contrast and slip documentation are assessed separately for the selected product; a product report does not replace the layout plan.
Frequently asked
Does every ribbed surface mean guidance?
No. The function follows the country’s layout scheme and application; some transverse ribbed surfaces are used to warn of a hazard.
Does the schematic drawing define manufacturing dimensions?
The drawing shows two complete plates and the counts of 50 domes and 8 bars. Plate thickness, relief height, element diameter and spacing are not inferred from this view; confirm them against the selected model datasheet.
Does anti-slip coating serve the same function as a tactile surface?
Slip resistance and texture sensed by a cane or foot are separate properties. Anti-slip coating alone does not define a warning or guidance pattern.
Can layout dimensions be derived from plate dimensions?
No. Position, setback, warning field and route direction follow the project country’s accessibility guidance and layout drawing.
